4" - 6" Lift w/ Bilstein Shock Absorbers - Chevy/GMC 4 Door Tahoe/Yukon 4WD

4"-6" Suspension System w/ Bilstein 5100 Series Shock Absorbers - 1995-1999 Chevrolet / GMC, 6-lug, 1500 Tahoe, Yukon, 4 Door IFS, 4wd


Part #: 10-41095


MSRP: $2,130.00 USD

More details

RCD builds kits that not only provides the ride you want on the street but give you the performance you deserve on rugged terrain. The first company to design, develop and produce kits with the replacement spindle, RCD boasts nearly two decades of quality workmanship, materials and design - all made in the USA. GM kits, the shining diamond in RCD's crown, are rated as some of the best in the industry. Don't settle for less, insist on RCD Suspension.
CNC machined replacement cast iron steering knuckles, T-6 billet aluminum axle spacers, 2-piece lower sub-frame assembly & polished stainless steel, CNC machined zinc plated billet steel sway bar links with oversized urethane bushings. Kit can be purchased with Bilstein shock absorbers or without shocks giving you the flexibility to choose what fits into your budget.



This kit is compatible with:

  •  1995-1999 GMC Yukon 4DR - 4WD
  •   1995-1999 GMC Tahoe 4DR - 4WD

This kit includes:
 -Front & rear crossmembers
  -Front spindles
  -Lateral compression strut kit
  -Main kit
  -Bilstein 5100 Series Shock Absorbers

Tire/Wheel Specifications:
  Max Tire Size: 33" x 12.5" w/ no modifications necessary. 35" & larger x 12.5" require minor fender and/or bumper trimming.

  Max Backspace: 16" x 8" - 4.5" backspacing. 16.5" & larger x 8" = 4.75" backspacing.

Additional Information:
  -Will NOT work with Air Ride or Electronic Suspension Systems

  -Recalibration of the speedometer, ABS and stability control systems (if applicable) will be required by an authorized GMC/Chevy Dealer
  -Must enlarge lower control arm sway bar end link mounting hole to 3/4”
  -Front system increases vehicle track width 2” for added stability
  -Some models may require an exhaust modification to clear the front driveshaft
